Product Description
- Smaller size – similar in size to the existing USB 2.0 Micro-B
- Support power charge – Type-C connector and cable will support scalable power charging
- Scalability – the connector design will scale for future USB bus performance
- Usability enhancements – users will no longer need to be concerned with plug orientation/cable direction, maling it easier to plug in
Product Application
- Storage Tablet PC
- Game console Vehicle peripheral
- Smartphone Notebook
- Display Docking
Features
Product Name | Product Description | Type | Center Height | Notes |
8196-3C24-0271 | Mid Mount | Hybrid | -0.32mm | NA |
8196-3H24-EC71 | Mid Mount | Hybrid | 0.75mm | NA |
8196-3524-PG71 | Mid Mount | Dual SMT | -0.53mm | NA |
8196-3524-J680 | Top Mount | Dual SMT | 1.8mm | NA |
8196-3524-J780 | Top Mount | Dual SMT | 1.8mm | NA |
8196-3524-B880 | Top Mount | Dual SMT | 1.8mm | NA |
8196-3H24-T580 | Top Mount | Hybrid | 3.4mm | NA |
8196-3624-AB71 | R/A | DIP | N/A | NA |
8196-3524-WP71 | Water proof(IPX7) | Dual SMT | 0.5mm | NA |
8196-3A16-6471 | MIM | DIP | 2.05mm | NA |
